Ck40L Slant Bed CNC Lathe Machine Basic Info.
Model NO.：CK40L-750
Controller：Siemens808d Ver.15
Max. Swing Over Bed：Φ400mm
Distance Between Centers：750mm
Hydraulic Chuck：200mm
Spindle Bore：66mm ( 50mm After Hydraulic Chuck )
Max. Process Length：600mm
Spindle Motor：7.5kw GSK Servo Motor
Spindle Seed：4000rpm
Max. Swing Over Cross Slide：Φ220mm
Turret：8 Station (20X20mm)
Spindle Nose：A2-6
Tailstock：Hydraulic Tailstock
Transport Package：Fumigation Package
Specification：3.30*2.22*2.28 M
Trademark：ZINO
The hot selling products of ZINO factory include Numerical control lathe,vertical machining center 1160,machining center 850,VMC1160,VMC850,lathe C0636,conventional lathe CS6250,Manual lathe C6266,ordinary lathe GH1440,lathe GH1440K,lathe CM6241,common lathe SN50,TOS,torno C0636,torno CS6250,torno GH1440K,cnc lathe machine CK6150,cnc lathe machine CK6166H, cnc lathe CK300,turning machine CK500,Inclined bed CNC lathe TC500 and other series of products
Origin：Jiangsu Province
HS Code：8458110090
Production Capacity：200 Pieces / Year
